Raceline Wheels RT260-78560-19 - Avenger Beadlock - 17x8.5 - 6x5.5 Bolt Pattern - -19mm Offset / 4" Backspacing - Off-Road Beadlock Wheel

The Raceline Wheels RT260-78560-19 Avenger Beadlock is a heavy-duty off-road wheel engineered for extreme performance and durability. This 17x8.5 beadlock wheel features a 6x5.5 bolt pattern with -19mm offset and 4-inch backspacing, making it ideal for trucks and SUVs running aggressive off-road setups.

Key Features:

• Classic 8-spoke design with cast-in Raceline logo
• Heavy-duty A356 aluminum construction
• Forged 6061 aluminum beadlock ring
• US-made Grade 8 zinc beadlock hardware
• Hardened steel PEM-nuts with captive washers (replaceable)
• Engineered to be one of the strongest wheels available

Technical Specifications:

• Part Number: RT260-78560-19
• Size: 17 x 8.5 inches
• Bolt Pattern: 6x5.5 (6x139.7mm)
• Offset: -19mm
• Backspacing: 4 inches
• Construction: A356 aluminum wheel center
• Beadlock Ring: Forged 6061 aluminum
• Beadlock Bolt Length: 1.50 inches (17" aluminum bolts)
• Hardware: US-made Grade 8 zinc-plated steel


Beadlock Technology: The RT260 Avenger features a true beadlock design that mechanically clamps the tire bead to the wheel using a forged aluminum outer ring and Grade 8 hardware. This prevents tire bead separation during low-pressure off-road use, providing superior traction and control in extreme terrain.

Replaceable Hardware System: Unlike traditional beadlock wheels where stripped threads render the wheel worthless, the Avenger uses hardened steel PEM-nuts with captive washers that can be replaced as needed. This industry-leading design ensures long-term serviceability and value.

Construction Quality: The wheel center is constructed from heavy-duty A356 aluminum alloy, known for its excellent strength-to-weight ratio and casting properties. The beadlock ring is forged from 6061 aluminum for maximum strength and durability. All beadlock hardware is US-made Grade 8 zinc-plated steel for corrosion resistance and reliability.

Bolt Pattern Compatibility: The 6x5.5 (6x139.7mm) bolt pattern fits:

• Chevrolet Silverado 1500
• GMC Sierra 1500
• Chevrolet Tahoe / Suburban
• GMC Yukon / Yukon XL
• Cadillac Escalade
• Toyota Tacoma
• Toyota 4Runner
• Toyota FJ Cruiser
• Nissan Titan
• Nissan Frontier
• And other vehicles with 6-lug 5.5" bolt circle

Offset and Backspacing: The -19mm offset (4-inch backspacing) provides aggressive wheel placement, pushing the tire outward for improved track width and clearance for larger tires and suspension components. This offset is popular for lifted trucks and SUVs running 33-inch to 37-inch tires.

Beadlock Ring Spacers: For thicker beaded tires, Raceline beadlock ring spacers are available separately to ensure proper ring seating and clamping force.

Custom Options Available:

• Custom bolt patterns can be drilled to specifications
• Custom hub bores available
• Special desert racing lug seats (noted by "DBP" in SKU)

What's NOT Included:

• Center caps (sold separately)
• Lug nuts (sold separately)
• Beadlock ring spacers (sold separately if needed)
• Tire and mounting

Raceline Heritage: Family-owned since 1996, Raceline has been a market leader in the design and manufacturing of wheels for off-road, street, and track use. Founded as a manufacturer of specialty wheels for the off-road racing segment, Raceline's passion for performance continues to inspire its entire product line.

Performance Applications:

• Rock crawling and technical trails
• Desert racing and pre-running
• Overlanding and adventure travel
• Off-road parks and competitions
• Extreme 4x4 builds
• Lifted trucks and SUVs

Maintenance:

• Inspect beadlock bolts regularly for proper torque
• Re-torque after initial installation (50-100 miles)
• Check torque before each off-road trip
• Clean wheel and beadlock ring regularly
• Inspect for cracks, damage, or deformation
• Follow Raceline's wheel care guidelines

Warranty: Raceline wheels are backed by a limited warranty. See manufacturer documentation for complete details.

California Prop 65 Warning: This product may contain chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

Complementary Products:

• Raceline center caps for RT260 Avenger
• Appropriate lug nuts for 6-lug applications
• Beadlock ring spacers (if needed for thick-beaded tires)
• Beadlock assembly tools and torque wrenches

Transform your truck or SUV with the proven strength and performance of Raceline RT260 Avenger Beadlock wheels—engineered for serious off-road enthusiasts who demand the best.

The Official Wheel of King of the Hammers
