Mr. Gasket 80 GPH Mechanical Fuel Pump

Mr. Gasket mechanical fuel pumps range from 80 to 110 GPH (gallons per hour) in many various applications to cover most Chevrolet, Ford, Chrysler and Pontiac V-8 engines. Suitable for street use and high output racing applications when a mechanical pump is desired or required.

• Street Performance
• Flows 80 GPH free flow
• Shutoff pressure pre-set at 7.5 PSI
• Fuel pressure regulator is not required due to built-in shutoff
• Heavy duty construction for continuous high rpm operation
• Lower pump body can be clocked in different positions to tailor to your specific orientation needs
• Inlet & outlet tapped for 1/4" NPT

Specifications

• Application: Chevrolet Big Block
• Brand: Mr. Gasket
• Category: Air and Fuel Delivery
• Color: Silver
• Emission Code: 5
• Free Flow GPH: 80
• Fuel Type: Gasoline
• Inlet Size: 1/4 inch NPT
• Material: Aluminum
• Outlet Size: 1/4 inch NPT
• Part Type: Mechanical Fuel Pump
• Product Type: Fuel Pump
• Sub Category: Fuel Pumps and Related Components
• Warranty: Manufacturer's Limited 90 Day Warranty
• Part Number: 7704MRG
